Product Description
- 6 Time ranges
- LED Indications : Power ON, Relay ON
- Cyclic timer with Unequal ON & OFF Time
- Universal supply voltage, Finger safe terminals
| Output Contact | 2 C/O (DPDT) |
| Operating Modes | Asymmetrical Cyclic ON first or OFF first |
| Counting Direction | Down |
| Accuracy | Setting:±0.1 of set time or ±50 m sec (whichever is greater) For Y contact operation: + 100 m sec, Repeat: ± 0.1% |
| Range | 1/10/sec/min/hr for both ON & OFF time |
| Supply Voltage | 20 to 240V AC, 12 to 140V AC |
| Size | 22.5 mm |
| Mounting Type | DIN rail mount |
| Certification | CE & UL |
